Description

Specifications

• 2" - 24" (DN 50 - DN 600)
• Maximum Working Pressure : 16 bar
• ANSI 150.300, PN 10-16, JIS 10K / ANSI 300
• Face to Face : EN558 - ISO 5752 - BS 5155 - API 609
• ISO 5211 Mounting Pad
• Flange connections according to ANSI Class 150, 300, PN 10-16, JIS 10K
  Body Material : Ductile Iron, Cast Iron, Cast Steel, Stainless Steel
  Disc Material : Ductile Iron, Stainless Steel
  Seat Material : EPDM -20°C to +120°C
                         NBR -10°C to +90°C



Operation Options

• Lever Operator
• Gear Operator
• Pneumatic Actuator
• Electric Actuator
